Figure 3-4. Configuration Modulator Menu - Comtech EF Data SLM-3650 Installation And Operation Manual

SLM-3650 Satellite Modem
Operation
SLM3650 "TYPE"
VER: X.X.X
TX-X QPSK 1/2
See Description Table.
TX POWER LEVEL
-
5.0 to -30.0 dBm (normal range)
+5.0 to -20.0 dBm (high power option)
-129 to +104 dBm (user adjusted)
CARRIER MODE
Normal-Modulated
Center-CW
Offset-CW
Dual-CW
