CDM-570A/570AL Satellite Modem with Optional Packet Processor
Serial-based Remote Product Management
Command
Parameter (Instruction
Type Code and
Qualifier)
RTC Date DAY= 6 bytes
RTC Time TIM= 6 bytes
EDMAC Framing EFM= 1 byte,
Mode value of 0, 1 or 2
EDMAC Slave ESA= 4 bytes
Address Range
External ERF= 1 byte,
Reference value of 0 thru 5
Frequency
Arguments for
Command or
Response to
Query
Command or Query.
Sets or returns the date in the form ddmmyy, where
dd = day of the month (01 to 31),
mm = month (01 to 12)
yy = year (00 to 99)
Example: <0/DAY=240457 (April 24, 2057)
Command or Query.
Sets or returns the time, from midnight, in the form hhmmss, where:
hh = hours (00 to 23)
mm = minutes (00 to 59)
ss = seconds (00 to 59)
Example: <0/TIM=231259 (23 hours:12 minutes:59 seconds)
Command or Query.
Sets or returns EDMAC mode in the form x, where:
0 = EDMAC OFF (Framing is on, AUPC active)
1 = EDMAC MASTER
2 = EDMAC SLAVE (Query Only)
Example: <0/EFM=1 (EDMAC Enabled as Master)
Command or Query.
Valid only for an EDMAC Master.
Sets or returns EDMAC Slave Address Range, where:
As a command, sets the range of addresses of distant-end units (modems or
transceivers) for which this unit, as the Master, forwards messages.
Example: <0/ESA=0090
As a query, it may be sent to an EDMAC slave, which responds with the
appropriate address.
Note: Only values that are integer multiples of ten are permitted. (0010, 0020,
0030, 0040, etc.).
Command or Query.
Sets or returns External Reference Frequency in the form x, where:
0 = Internal
1 = External 1 MHz
2 = External 2 MHz
3 = External 5 MHz
4 = External 10 MHz
5 = Internal 10MHz plus output (the Reference is available on the "Ext Ref" rear
connector (small rear-panel LED indicates when ON))
Example: <0/ERF=0 (External reference not used – uses internal)
Description of Arguments
8–24
MN-CDM570A
Revision 3
Query
Response to
(Instruction Code
Command
and Qualifier)
DAY= DAY? DAY=ddmmyy
DAY? (see Description of
DAY* Arguments)
DAY#
TIM= TIM? TIM=hhmmss
TIM? (see Description of
TIM* Arguments)
TIM#
EFM= EFM? EFM=x
EFM? (see Description of
EFM* Arguments)
EFM#
ESA= ESA? ESA=xxxx
ESA? (see Description of
ESA* Arguments)
ESA#
ERF= ERF? ERF = x
ERF? (see Description of
ERF * Arguments)
ERF #
Response to
Query
