Comtech EF Data CDM-570A Installation And Operation Manual page 401

CDM-570A/570AL Satellite Modem with Optional Packet Processor
CDM-570A/570AL ODU (Transceiver, BUC, LNB) Operation
(KST SELECT: ► INFO:) HPA
HPA: On
Fault Logic: No Summary
This screen shows the current HPA configuration: HPA (ON or OFF) and Fault Logic
(Summary or No Summary).
(KST SELECT: ► INFO:) LNA
LNA: On
Fault Logic: No Summary
This screen shows the current LNA configuration: LNA (ON or OFF) and Fault Logic
(Summary or No Summary).
(KST SELECT: ► INFO:) Equip (Equipment)
EQUIP-TYPE: KST-2000A
HPA-TYPE: CEFD-SSPA
This screen shows the currently installed ODUs: The transceiver, high-power amplifier, and
solid-state power amplifier.
(KST SELECT: ► INFO:) Assembly+SN
ASSEMBLY INFO:
AS:11565-4
The blinking cursor is on the M&C. Use the ▲▼arrow keys to view additional
assembly and S/N information for the Up Converter, Down Converter, and HPA.
(KST SELECT: ► INFO:) FW (Firmware)
FIRMWARE INFO:
FW:10303-1D
The blinking cursor is on the M&C. Use the ▲▼arrow keys to view additional
assembly and S/N information for the Up Converter, Down Converter, and HPA.
M&C
SN:001370891
M&C
VER:01.01.05
10–23
MN-CDM570A
Revision 3
