CDM-570A/570AL Satellite Modem with Optional Packet Processor
Optional Packet Processor - Serial/Telnet CLI Operation
Screen Prompt
Specify Protocol for the rule
(continued)
Specify priority for the rule
Maximum bandwidth in kbps
<0-99999, enter = 99999>:
Source IP address
<enter = 0.0.0.0>:
Number of Source subnet bits
<0,8-32, enter = 0>:
Destination IP address
<enter = 0.0.0.0>:
Number of Destination subnet
bits <0,8-32, enter = 0>:
Specify TCP/UDP source port
[MIN] (1-65535) <Enter: ***>
Specify TCP/UDP source port
[MAX] (1-65535) <Enter: ***>
Specify TCP/UDP destination
port [MIN] (1-65535) <Enter:
***>
Specify TCP/UDP destination
port [MAX] (1-65535) <Enter:
***>
Set WRED (Weighted Random
Early Discard)
<Y or N> <Enter : Y>
Specify Filtering for the rule
<Y or N> <Enter : N>
Action
7 for RTPS (RTP Signaling)
8 for FTP (File Transfer Protocol only)
9 for HTTP (Hypertext Transfer Protocol)
10 for TELN (Telnet)
11 for SMPT (Simple Mail Transfer Protocol)
12 for SNMP (Network Management Protocol)
13 for SAP (Service Announcement Protocol)
14 for ORCL (Oracle application traffic)
15 for CTRX (Citrix application traffic)
16 for SQL (Structured Query Language)
17 for IP (Internet Protocol (all inclusive))
18 for N-IP (Non-Internet Protocol (all inclusive))
Where Priority 1 = Highest, and Priority 8 = Lowest:
1 for QoS Priority-1
2 for QoS Priority-2
3 for QoS Priority-3
4 for QoS Priority-4
5 for QoS Priority-5
6 for QoS Priority-6
7 for QoS Priority-7
8 for QoS Priority-8
Type your Maximum Bandwidth, in kbps, from 0 to 99999. If you desire no such
parameter, press [Enter] – the bandwidth defaults to '99999'.
Type your Source IP Address in the form XXX.XXX.XXX.XXX. If you desire no
Source IP Address, press [Enter] – the address displays as '***'.
Type your Source subnet bits value, from 8 to 32. If you desire no Source subnet.
type '0' or press [Enter] – the subnet displays as '/*'.
Type your Destination IP Address in the form XXX.XXX.XXX.XXX. If you desire no
Destination IP Address, press [Enter] – the address displays as '***'.
Type your Destination subnet bits value, from 8 to 32. If you desire no Destination
subnet. type '0' or press [Enter] – the subnet displays as '/*'.
Set the minimum TCP/UDP source port in your range, from 1 to 65535.
If you desire no minimum TCP/UDP source port, press [Enter] – the port displays as
'***'.
This prompt will not display if you do not select a MIN TCP/UDP source port.
Set the maximum TCP/UDP source port in your range, from 1 to 65535.
Set the minimum TCP/UDP destination port in your range, from 1 to 65535. If you
desire no minimum TCP/UDP destination port, press [Enter] – the port displays as
'***'.
This prompt will not display if you do not select a MIN TCP/UDP destination
port. Set the maximum TCP/UDP destination port in your range, from 1 to 65535. If
you desire no maximum TCP/UDP destination port, press [Enter] – the port displays
as '***'.
Type 'Y' to enable, or 'N' to disable, Weighted Random Early Detect.
Type 'Y' to filter traffic (i.e., prevent traffic defined in rule from being forwarded).
Otherwise. type 'N' or press [Enter] to forward all traffic (no filtering) – this is the
default setting.
