CDM-570A/570AL Satellite Modem with Optional Packet Processor
Front Panel Operation
New Config has been
Loaded from Loc 8 (ENT)
Once you properly load a modem configuration, press ENTER or CLEAR to return to the previous
menu.

6.3.7 SELECT: Util (Utility)

UTIL: Buf Clock Ref CMO
ID 1:1 VFD Firmware FAST
◄ ►
Use the arrow keys to select a parameter. Press ENTER.
See Sect. 6.2 for use of the CMO (CDM-570 Compatible Mode) feature.
6.3.7.1

UTIL: Buf (Buffer Re-CENTER)

Press ENTER to Re-CENTER
the Receive Buffer
Press ENTER to force re-centering of the Plesiochronous/Doppler buffer.
6.3.7.2

UTIL: Clock (Set Real-time Clock)

Edit Real-Time Clock:
12:00:00 24/04/13(◄ ►,▲ ▼)
To edit the time and date settings of the real-time clock, use the
digit to edit. Then, use the ▲▼arrow keys to change that digit. Press ENTER.
In accordance with European convention, the date appears in DAY-MONTH-YEAR
format.
6.3.7.3

UTIL: Ref (Reference)

Internal Freq Ref:Adjust

Warm-up delay (◄ ►,ENTER)
◄ ►
Use the arrow keys to select Adjust or Warm-up delay. Press ENTER.
6.3.7.3.1 (Internal Freq Ref:) Adjust
Internal 10 MHz Freq Ref
Fine Adjust:+017(◄ ►,▲ ▼)
◄ ►
6–56
MN-CDM570A
Revision 3
arrow keys to select the
