CDM-570A/570AL Satellite Modem with Optional Packet Processor
Optional Packet Processor - Serial/Telnet CLI Operation
Selection
VLAN Filtering
VLAN ID 1 through 10
Hot Key Description
Each remote modem must have Remote Mode enabled,
indicating this is a distant-end modem.
F
Toggle bridging for all "Brouted" VLAN destination packets and routing of
non-VLAN traffic as [Enabled] or [Disabled].
0001
Assign a numeric VLAN ID in the range from 0001 to 4094.
thru
4094
The VLAN ID is a 12-bit field in the Ethernet packet that
contains the IEEE-802.1Q tag.
VLAN ID 0001 is reserved and used for normal switch
•
operation.
A maximum of 10 VLAN ID matches are supported.
•
Unused VLAN ID match fields must be set to values that
DO NOT match any network VLAN IDs.
