CDM-570A/570AL Satellite Modem with Optional Packet Processor
Front Panel Operation
6.3.5.9

INFO: Ref (Frequency Reference)

Frequency Reference:
Internal 10 MHz (ENTER)
This screen displays the configured external frequency reference source for the modem.

6.3.5.10 INFO: ID (Circuit ID)

Circuit ID:
24 CHARACTER TST MESSAGE
This screen displays the user-defined Circuit ID string that you can compose via the UTIL: ID
submenu.

6.3.5.11 INFO: 1:1 (1:1 Redundancy)

Redundancy State:Standby
Serial 1:1 Link: Active
•
On the top line: This screen displays the Redundancy State (1:1 or 1:N) as Online or
Standby
•
On the bottom line: This screen indicates the status of the serial link between the two units
as Active or Idle.

6.3.6 SELECT: Save/Load

Save/Load Configuration:
Save Load
This menu branch allows the saving (storage) or loading (retrieval) of up to 10 different modem
configurations (0 through 9) in the non-volatile memory of the modem. Use the
to select Save or Load. Press ENTER.
6.3.6.1

(Save/Load Configuration:) Save

Use the ▲▼arrow keys to select the location you wish to Save (store) the current
configuration. Press ENTER. Locations 0 through 9 are available.
Using Location 9 as an example: If you select Save and the chosen location is empty, the
screen appears as follows:
Save Config to Loc: 9
Empty
(ENTER)
(◄ ►,ENTER)
(▲ ▼)
6–54
MN-CDM570A
Revision 3
◄ ►
arrow keys
