DMD1050TS Initial Configuration Check

CAUTION – EQUIPMENT DAMAGE
Make sure to select the DMD1050TS Interface Type (MIL-188-114A or Ethernet
Data Interface) before you install the mating connectors. Failure to do this can
cause damage to the Data Interface.
The DMD1050TS is shipped from the factory with preset factory defaults. Upon initial power-up,
do a user check to examine the shipped modem configuration.

2.5.1 Standard DMD1050TS Factory Configuration Settings

Use of Strap Code 26 can set the modem configuration. For an explanation and listing of
available Strap Codes, see Appendix G. The Frequency and Modulator Output Power are set
independently of the strap code.
Data Rate:
Mode:
Satellite Framing:
Scrambler:
Inner FEC:
Outer FEC:
Modulation:
Frequency:
Modulator Output Power:
Data Rate:
Mode:
Satellite Framing:
Scrambler:
Inner FEC:
Outer FEC:
Modulation:
Frequency:
CAUTION – NETWORK MALFUNCTION
Using the modem's loopback capabilities with the Ethernet data interface can
cause undesirable network loops. Before you do any data test with an Ethernet
interface, make sure to use two modems connected back-to-back. If you use one
modem and a loopback, it can cause unwanted results.
To lock up the modem:
•
Enter IF Loopback Enable in the Test Menu
- or -
•
Connect a Loopback Cable from TX port to RX port
Installation
DMD1050TS Satellite Modem Board
Modulator:
2.048 Mbps
Closed Network
None
V.35 (IESS)
1/2 Rate Viterbi
Disabled
QPSK
950 MHz
-20 dBm
Demodulator:
2.048 Mbps
Closed Network
None
V.35 (IESS)
1/2 Rate Viterbi
Disabled
QPSK
950 MHz
