Satellite Modem > Monitor > Stored Events - Comtech EF Data CDM-570A Installation And Operation Manual

CDM-570A/570AL Satellite Modem with Optional Packet Processor
Optional Packet Processor - Serial/Telnet CLI Operation
9.3.8.2.1 Satellite Modem > Monitor > Stored Events
Open the nested Stored Events page from the Monitor page.
Selection
Number of Unviewed Stored
Events
Jump To First Stored Event
View Next 5 Stored Events
Clear All Stored Events
Figure 9-38. Stored Events
Hot Key Description
Displays the total number of unread stored events. As stored event
[RO]
groups are displayed, the counter decrements accordingly.
Upon selection, sets the listings for Hot Key 'V' to the first event that
J
was stored subsequent to the latest buffer reset.
Buffers the next group of five stored events into the events window.
V
Event information is presented as shown in Figure 9-38.
C Erases all entries from the stored events logging buffer.
9–55
MN-CDM570A
Revision 3
