Comtech EF Data CDM-570A Installation And Operation Manual page 257

CDM-570A/570AL Satellite Modem with Optional Packet Processor
Serial-based Remote Product Management
Command Arguments for
Parameter (Instruction
Type Code and
Qualifier)
Tx FEC Code TCR= 1 byte, value of 0
Rate thru 7, A to R
Tx Data Rate TDR= CDM-570A
Compatible
Mode: 9 bytes
CDM-570
Compatible
Mode: 8 bytes
Command or
Response to
Query
Command or Query.
Sets or returns Tx Code Rate in the form x, where:
0 = Rate 5/16 (Turbo Only)
1 = Rate 21/44 (Turbo Only)
2 = Rate 1/2
3 = Rate 2/3 (8-PSK TCM or 8-QAM only)
4 = Rate 3/4
5 = Rate 7/8
6 = Rate 0.95 (Turbo Only)
7 = Rate 1/1 (Uncoded or No FEC)
8 = Reserved
9 = Reserved
(The remaining entries are valid only in CDM-570A Compatible Mode (CMO=1)):
A = VersaFEC CCM – BPSK Rate 0.488
B = VersaFEC CCM – QPSK Rate 0.533
C = VersaFEC CCM – QPSK Rate 0.631
D = VersaFEC CCM – QPSK Rate 0.706
E = VersaFEC CCM – QPSK Rate 0.0803
F = VersaFEC CCM – 8-QAM Rate 0.576
G = VersaFEC CCM – 8-QAM Rate 0.642
H = VersaFEC CCM – 8-QAM Rate 0.711
I = VersaFEC CCM – 8-QAM Rate 0.780
J = VersaFEC CCM – 16-QAM Rate 0.644
K = VersaFEC CCM – 16-QAM Rate 0.731
L = VersaFEC CCM – 16-QAM Rate 0.780
M = VersaFEC CCM – 16-QAM Rate 0.829
N = VersaFEC CCM –16-QAM Rate 0.853
O = VersaFEC CCM ULL– BPSK Rate 0.493
P = VersaFEC CCM ULL– QPSK Rate 0.493
Q = VersaFEC CCM ULL– QPSK Rate 0.654
R = VersaFEC CCM ULL– QPSK Rate 0.734
Note: Selection availability depends on the active FEC and Modulation type.
Example: <0/TCR=4 (Rate 3/4)
Command or Query.
Sets or returns Tx Data rate in the form xxxxx.xxx, where:
xxxxx.xxx = value from 2.4 kbps to 10240 kbps
Resolution = 1 bps.
Examples:
1) <0/TDR=02047.999 (2047.999 kbps in CDM-570A Compatible Mode)
2) <0/TDR=2047.999 (2047.999 kbps in CDM-570 Compatible Mode)
Description of Arguments
8–13
MN-CDM570A
Revision 3
Query
Response to
(Instruction Code
Command
and Qualifier)
TCR= TCR? TCR=x
TCR? (see Description
TCR* of Arguments)
TCR#
TCR+
TDR= TDR? TDR=xxxxx.xxx
TDR? (see Description
TDR* of Arguments)
TDR#
Response to
Query
