Comtech EF Data CDM-570A Installation And Operation Manual page 269

CDM-570A/570AL Satellite Modem with Optional Packet Processor
Serial-based Remote Product Management
Command
Parameter (Instruction
Type Code and
Qualifier)
Internal 10MHz ADJ= 4 bytes, numeric
Reference
Adjustment
Warm-up Delay WUD= 1 byte,
value 0 or 1
Countdown CTD= 3 bytes
Unit Test Mode TST= 1 byte,
value of 0 thru 6
Number of Unread N/A 3 bytes
stored Events
Arguments for
Command or
Response to
Query
Command or Query.
Sets or returns fine adjustment of the modem Internal 10MHz Reference in the
form sddd, where:
s = sign (+ or –), and
ddd = value from 000 to 999
Command or Query.
Sets or returns Warm-up Delay for internal frequency reference (OCXO) in the form
x, where:
0 = Disabled (instant on – no delay for OCXO to reach temperature)
1 = Enabled (unit waits until OCXO reaches correct temperature)
Example: <0/WUD=1 (selects Warm-up Delay)
Command or Query.
As a command, only takes the argument 000. Truncates the Warm-up delay
period to zero and forces the unit into 'instant-on' mode. For example, CTD=000
terminates the warm-up delay.
As a query, returns the Warm-up Delay countdown, in seconds remaining. Range
is from 000 to 200 seconds.
For example: <0/CTD?
>0/CTD=067 (means the unit will wait another 67 seconds before it
enters its operational state)
Command or Query.
Sets or returns the CDM/R-570AL Test Mode, where:
0 = Normal Mode (no test)
1 = IF Loopback
2 = Digital Loopback
3 = I/O Loopback
4 = RF Loopback
5 = Tx CW
6 = Tx Alternating 1,0 Pattern
Example: <0/TST=1 (IF Loopback)
Query only.
Returns the number, in the form xxx, of stored events which remain unread over
the remote interface.
Example: <0/NUE?
>0/NUE=126
Description of Arguments
8–25
MN-CDM570A
Revision 3
Query
Response to
(Instruction Code
Command
and Qualifier)
ADJ= ADJ? ADJ=sddd
ADJ?
ADJ* Arguments)
ADJ#
WUD= WUD? WUD=x
WUD? (see Description of
WUD* Arguments)
WUD#
CTD= CTD? CTD=xxx
CTD? (see Description of
CTD* Arguments)
CTD#
TST= TST? TST=x
TST? (see Description of
TST* Arguments)
TST#
N/A NUE? NUE=xxx
(see Description of
Arguments)
Response to
Query
(see Description of
