CDM-570A/570AL Satellite Modem with Optional Packet Processor
Front Panel Operation
◄ ►
Use the
(CONFIG: TI) G.703: T1  Length
T1 Line Length:
000-133 feet (▲ ▼,ENTER)
The valid length spans, in feet, are 0-133, 133-266, 266-399, 399-533, or 533-655.
Use the ▲▼arrow keys to select the desired span. Press ENTER.
(CONFIG: TI) G.703: T1  Line-Code
T1 Line Code (B8ZS):
On
Use the
(CONFIG: TI) G.703  E1-Bal or E1-Unbal
E1 Line Code (HDB3):
On Off
When you select E1-Bal or E1-Unbal, the modem displays this typical submenu.
◄ ►
Use the
6.3.2.7.4

(CONFIG: TI) IP-ACM

This selection is functional only when the optional Packet Processor is installed.
ACM:ModCod Unlock-Action
Target-SNR-Margin
◄ ►
Use the arrow keys to select a parameter. Press ENTER.
(CONFIG: TI) IP-ACM  ModCod
Min ModCod:11 16QAM .853
Max ModCod:11 16QAM .853
Use the ◄ ►
range setting (on the bottom line). Then, use the
ModCods (00-11) over which the system will operate. Press ENTER.
ModCod 00 is BPSK Rate 0.488 (0.49 bps/Hz), while ModCod 11 is 16-QAM Rate 0.853
(3.41bps/Hz).
arrow keys to select Length or Line Code. Press ENTER.
Off(AMI) (◄ ►,ENTER)
◄ ►
arrow keys to select On or Off. Press ENTER.
(◄ ►,ENTER)
arrow keys to set operation as On or Off. Press ENTER.
arrow keys to select the Min(imum) (on the top line) or Max(imum) ModCod
arrow keys to define the range of
▲▼
6–34
MN-CDM570A
Revision 3
