Appendix N. 1:1 IP REDUNDANCY

N.1

Overview

CAUTION – This equipment contains parts and assemblies sensitive to damage by
Electrostatic Discharge (ESD). Use ESD precautionary procedures when touching,
removing, or inserting Printed Circuit Boards (PCBs).
•
Chapter 9. OPTIONAL PACKET PROCESSOR – SERIAL/TELNET CLI OPERATION
•
Appendix D. OPTIONAL HIGH-PERFORMANCE PACKET PROCESSOR
The CDM-570AL and CDMR-570AL L-Band Satellite Modems may be referred to
throughout this appendix, collectively, as the CDM/R-570AL.
This appendix also identifies the CDM-570A, CDM-570AL, or CDMR-570AL Satellite
Modems, as equipped with the optional High-Performance Packet Processor,
collectively as the CDM-570A/570AL-IP.
The CDM-570A/570AL-IP and other compatible, IP-centric Comtech EF Data modems
may also be generically referred to throughout this appendix as the CDM-IP.
The CDM-570A/570AL-IP can be configured for 1:1 IP Redundancy as a standard feature when
used with a Comtech EF Data CRS-180 (70/140 MHz IF) or CRS-170A (L-Band) 1:1 Redundancy
Switch:
Modem Type
CDM-570A-IP (70-140 MHz IF)
CDM/R-570AL-IP (L-Band)
This appendix describes CDM-570A/570AL-IP 1:1 IP Redundancy configuration and operation
using either of these switches.
CRS Switch Model
CRS-180
CRS-170A
N–1
