Comtech EF Data CDM-570A Installation And Operation Manual page 284

CDM-570A/570AL Satellite Modem with Optional Packet Processor
Serial-based Remote Product Management
Command
Parameter (Instruction
Type Code and
Qualifier)
Equipment ID in
CDM-570A
Compatible Mode
(CMO=1)
(continued)
Arguments for
Command or
Response to
Query
h = CnC Datarate option:
0 = None
1 = full up to 512 kbps
2 = full up to 1100 kbps
3 = full up to 2500 kbps
4 = full up to 5000 kbps
5 = full up to 10239 kbps
6 = fractional up to 2500 kbps
7 = fractional up to 5000 kbps
8 = fractional up to 10239 kbps
i = CnC APC option:
0 = None
1 = Installed
j = Carrier ID option:
0 = None
1 = Installed
k = spare (0):
l = BUC option:
0 = None
1 = 100 Watt
2 = 150 Watt
m = G.703 Clock Extension:
0 = None
1 = Installed
n = VersaFEC ACM symbol rate option:
0 = None
1 = up to 375ksps
2 = up to 750ksps
3 = up to 1500ksps
4 = up to 2000ksps
5 = up to 3000ksps
o = 3xDES Encryption option:
0 = None
1 = Installed
p = IP Header Compression option:
0 = None
1 = Installed
q = IP Payload Compression option:
0 = None
1 = Installed
Description of Arguments
8–40
MN-CDM570A
Revision 3
Query
Response to Response to
(Instruction Code
Command
and Qualifier)
Query
