CDM-570A/570AL Satellite Modem with Optional Packet Processor
Serial-based Remote Product Management
Command
Parameter (Instruction
Type Code and
Qualifier)
Global
Configuration in
CDM-570A
Compatible Mode
(CMO=1)
(continued)
Arguments for
Command or
Response to
Query
o = AUPC Enable
ppp.pp = AUPC parameter setup
q = Warm-up delay
rr = G.703 Clock Extension
s = Tx Alpha
t = Tx Clock Invert
xxx = 3 expansion bytes
AAAA.AAAA = Rx Frequency
B = Rx FEC Type
C = Rx Modulation Type
D= Rx FEC Rate
EEEEE.EEE = Rx Data Rate
F = Rx Spectrum Inversion
G = Rx Descrambler state
H = Rx Data Invert
III = Rx Sweep Width
JJ.J = Eb/No Alarm Point
K = Rx Buffer Size
L = Rx Alpha
M = Rx Clock Invert
xxxxxx = 6 expansion bytes
N = External Reference Frequency
O = EDMAC Framing Mode
PPPP = EDMAC Slave Address
Q = Unit test Mode (Read only)
RRRRRRRRRRRR = Unit Alarm Mask
S=RTS/CTS Control
T = Statistics Sampling Interval
U = Attach BUC Alarm to Tx Alarm
V = Attach LNB Alarm to Rx Alarm
xxxxxx = 6 expansion bytes
mMAT= ACM parameters
rrrr.rrr = Tx Symbol Rate
ssss.sss = Rx Symbol Rate
a = Tx BERT State
b = Tx BERT Pattern
x = expansion bytes
c = Rx BERT State
d = Rx BERT Pattern
e = CnC mode
Description of Arguments
same as AUP
same as APP
same as WUD
same as CEX
same as TXA
same as TCI
same as RFQ
same as RFT
same as RMD
same as RCR
same as RDR
same as RSI
same as RDS
same as RDI
same as RSW
same as EBA
same as RBS
same as RXA
same as RCI
same as ERF
same as EFM
same as ESA
same as TST
same as MSK
same as RTS
same as SSI
same as ABA
same as ALA
same as ACM
same as TSR
same as RSR
same as BTX
same as TBP
same as RTX
same as RBP
same as CNM
8–36
MN-CDM570A
Revision 3
Query
Response to Response to
(Instruction Code
Command
and Qualifier)
MGC?n Where n=0 to 9
Returns the MGC
portion of 1 of 10
stored
configurations (see
Description of
Arguments)
Query
