CDM-570A/570AL Satellite Modem with Optional Packet Processor
Introduction
Option
Optimized Transmit Filter Rolloff
(5%, 10%, 15%, 20%, 25%)
Primary Input Power Supplies
(without BUC P/S)
Primary Input Power Supplies
(with BUC P/S)

1.2.10 Supporting Hardware and Software

1.2.10.1 CDM-570AL/CDMR-570AL L-Band Redundancy

For 1:1 applications, the modem is supported by the low-cost external CRS-170A L-Band 1:1
Redundancy Switch.
For Hub applications, the modem is supported by the low-cost external CRS-300 1:N
Redundancy Switch coupled with the CRS-280L (L-Band) Redundancy Switch.

1.2.10.2 CDM-570A 70/140 MHz Redundancy

For 1:1 applications, the modem is supported by the low-cost external CRS-180 70/140MHz 1:1
Redundancy Switch.
For Hub applications, the modem is supported by the low-cost external CRS-300 1:N
Redundancy Switch coupled with the CRS-280 IF (70/140 MHz) Switch.

1.2.10.3 Support Software

The modem is supported by Comtech EF Data's SatMac (Satellite system Monitor and Control)
Version 4.7 software, a Windows
for the complete system of Comtech EF Data equipment (comprising Modems, Transceivers, and
Redundancy Switches).
Contact Comtech EF Data Product Support for more information or to order a free demo disk.
SatMac is also available for download from the M&C Utilities link on Comtech EF Data's website.
Description and Comments
Up to 512 kbps for CCM
Up to 1.1 Mbps for CCM
Up to 2.5 Mbps for CCM
Up to 5 Mbps for CCM
Up to 10.239 Mbps for CCM
100 to 240V AC
-24V DC
-48V DC
100 to 240V AC w/24V DC 90W @50°C BUC P/S
100 to 240V AC w/48V DC 150W @50°C BUC P/S
-24V DC w/24V DC 90W @50°C BUC P/S
-48V DC w/24V DC 90W @50°C BUC P/S
-48V DC w/48V DC 150W @50°C BUC P/S
TM
-based application that provides a 'point and click' interface
1–13
MN-CDM570A
Revision 3
Install Method
FAST
FAST
FAST
FAST
FAST
HW
HW
HW
HW
HW
HW
HW
HW
