1.1 I
NTRODUCTION
This quick start guide will allow a user to configure a pair of CiM-550 or CiM-300L
(referred to CiM in rest of the document) from beginning (i.e. starting from factory
default settings) and be able to pass traffic within minutes. It is assumed that the user is
familiar with the configuration of the base satellite modem.
1.2 T P
YPICAL OINT
The steps in this guide will lead to following configuration:
Ethernet Interface (fei0)
IP Address:
Mask: 255.255.255.0
HDLC Interfacce (hdl1)
IP Address:
Mask:
Satellite IP Modem (CiM 1)
IP Address:
Mask:
GW:
10/100 BaseT
Etherneet Hub

Chapter 1. Getting Started

- -P
TO OINT
172.16.10.10
10.1.1.1
255.255.255.0
172.16.10.100
255.255.255.0
172.16.10.10
PC 1

Figure 1. Typical Point-to-Point System Configuration

Introduction

Sample Configuration
Equipment List
Equipment Setup
PC Configuration
Transmit and Receive IF Configuration
Basic IP Configuration
Using Encryption
Using QoS
Other Configuration Items
S C
YSTEM ONFIGURATION
HDLC Interfacce (hdl1)
IP Address:
Mask:
Satellite IP Modem (CiM 2)
RF or IF
IP Address:
1
Ethernet Interface (fei0)
IP Address: 172.17.10.10
Mask: 255.255.255.0
10.1.1.2
255.255.255.0
172.17.10.100
Mask: 255.255.255.0
GW: 172.17.10.10
10/100 BaseT
PC 2
Etherneet Hub
1
1
1
2
2
3
3
8
11
11
