CDM-570A/570AL Satellite Modem with Optional Packet Processor
Ethernet-based Remote Product Management
7.4.3.3.4.3 Configuration | Routing | DHCP
Use this page to set up the DHCP (Dynamic Host Configuration Protocol) Relay feature.
DHCP allows a device to be configured automatically – eliminating the need for intervention by a
network administrator – and provides a server located at the hub for keeping track of devices
that are connected to the network. This prevents two devices from accidentally being
configured with the same IP Address.
DHCP Relay
• DHCP Server IP Address – Enter the IP Address to be used for the DHCP server at the hub in
the form XXX.XXX.XXX.XXX. Enter 0.0.0.0 to disable this feature.
Click [Submit] to save.
Make sure to also click [Save PaP Parameters] on the 'Admin | PaP Save' page before
proceeding further.

Figure 7-17. Configuration | Routing | DHCP page

7–38
MN-CDM570A
Revision 3
