CDM-570A/570AL Satellite Modem with Optional Packet Processor
Appendix L
4. The input data streams are as follows.
Stream
1
2
3
4
QUESTION: What are the total output data rates and the individual stream data rates?
ANSWER: The individual stream data rates are as follows.
QoS
QoS Priority
Rule
1 1
2 2
3 3
4 9
Total N/A
L.1.2

Min/Max (Minimum/Maximum Bandwidth) QoS Mode

In Min/Max mode, up to 32 QoS rules can be configured using source/destination IP subnet,
Layer 3 source/destination port range, and protocol (FTP, UDP, RTP, etc.). For each created rule,
you can also set the QoS treatment, such as guaranteed minimum bandwidth, maximum
clipping bandwidth, WRED enable or disable, and filter rule.
Minimum Bandwidth – Minimum specification that allows a committed information rate (CIR)
to be applied to user-defined classes of traffic; otherwise, the default of no minimum bandwidth
can be selected.
Maximum Bandwidth – This can be assigned to a flow to restrict the Maximum Bandwidth that
any particular flow will utilize; otherwise, the default of no bandwidth restriction can be
selected.
WRED – The Min/Max QoS mode allows selection of Weighted Random Early Detection (WRED).
When WRED is enabled for a specific queue, QoS randomly drops packets after reaching 50% of
the QoS queue.
Filtering – Any specific flow can be designated as filtered (see Max/Pri QoS Mode).
When the FILTER option is enabled for a rule, QoS provides the ability to filter the packet
completely.
Protocol Src IP
UDP ***/*
TCP ***/*
HTTP ***/*
IP ***/*
Input Data Rate
1024 Kbps
1024 Kbps
1024 Kbps
64 Kbps
3136 Kbps
Dest IP Src Port
***/* ***
***/* ***
***/* ***
***/* ***
QoS Output Data Rate
644 Kbps
due to max clipping
1024 Kbps
380Kbps
0
2048 Kbps
L–5
MN-CDM570A
Revision 3
Dest Port Steam Data Rate
*** 1024
*** 1024
*** 1024
*** 64
Remain Data Rate (After
Serving the Priority Queue)
1404 Kbps
304 Kbps
0 Kbps
0 Kbps
0 Kbps
