CDM-570A/570AL Satellite Modem with Optional Packet Processor
Optional Packet Processor - Serial/Telnet CLI Operation
Selection
Tx Carrier
Tx Clock Source
Tx Clock Inversion
Tx Filter Rolloff
Hot Key Description
C
Select the Tx carrier operation:
1 – OFF
2 – ON
3 – Rx-Tx Inhibit (turns off the transmitter if the Rx is not locked)
NOTE: In a 1:1 Redundant system, the standby modem will display
[External Control].
[RO]
Displays the configured Tx Clock Source.
A
Select the Tx clock inversion type:
1 – Normal
2 – Inverted
E
Select the Tx alpha filter rolloff:
1 – 0.35
2 – 0.25
3 – 0.20
4 – 0.15
5 – 0.10
6 – 0.05
9–43
