CDM-570A/570AL Satellite Modem with Optional Packet Processor
CDM-570A/570AL ODU (Transceiver, BUC, LNB) Operation
(KST CONFIG: ► KST RX:) LNA ► Fault-Logic
LNA Fault Logic: Summary
No-Summary
To control whether or not an LNA fault will activate the SUMMARY FAULT RELAY, use
the ◄ ► arrow keys to select Summary or No-Summary. Press ENTER when done.
(KST CONFIG: ► KST RX:) LNA ► Calibrate
Calibrate LNA Current?
Cal
Calibration allows the system to determine nominal LNA power consumption. This need
only be performed at initial installation.
Use the ◄ ► arrow keys to select Cal or Exit, and then press ENTER.
(KST CONFIG: ► KST RX:) LNB
LNB: State
Calibrate Band
Use the ◄ ► arrow keys to select State, Fault-Logic, Calibrate, or Band, and then press
ENTER.
(KST CONFIG: ► KST RX:) LNB ► State
(KST CONFIG: ► KST RX:) LNB ► Fault-Logic
(KST CONFIG: ► KST RX:) LNB ► Calibrate
The State, Fault-Logic, and Calibrate commands operate identically to those used for
the LNA (KST-2000A) unit.
Additionally:
(KST CONFIG: ► KST RX:) LNB ► Band
LNB Rx Band:
A
Use the ◄ ► arrow keys to select A, B, or C, and then press ENTER.
10.2.1.2.2.1.1.3
KST MISC: AGC Ref-Adjust
Use the ◄ ► arrow keys to select AGC or Ref-Adjust, and then press ENTER.
(◄ ►,ENT)
Exit (◄ ►,ENT)
Fault-Logic
(◄ ►,ENT)
B C (◄ ►,ENT)
(KST SELECT: ► KST CONFIG:) Misc (Miscellaneous)
(◄ ►,ENT)
(Displayed when ODU is KST-2000B unit)
(Displayed when ODU is KST-2000B unit)
