Comtech EF Data CDM-570A Installation And Operation Manual page 270

CDM-570A/570AL Satellite Modem with Optional Packet Processor
Serial-based Remote Product Management
Command
Parameter (Instruction
Type Code and
Qualifier)
Unit Alarm Mask MSK= 12 bytes
Retrieve next 5 N/A 75 bytes
unread Stored
Events
Arguments for
Command or
Response to
Query
Command or Query.
Sets or returns Alarm Mask conditions in the form abcdefghijkl, where:
a = Tx FIFO
b = G.703 BPV
c = Tx-AIS
d = Rx AGC Alarm
e = Eb/No Alarm
f = Rx-AIS
g = Buffer slip
h = Ext Reference alarm
i = BUC alarm
j = LNB alarm
k = G.703 Loss of Signal alarm (0 = unmasked, 1 = masked)
l = spare
Notes:
1) Query response of 0 (unmasked/active) or 1 (masked) is provided for each
parameter.
2) For argument k, if G703 CEx FAST option is not installed or Tx clock is not
Internal, only 1(masked) is allowed.
Example: <0/MSK=1110011100
Query only.
Returns the oldest 5 Stored Events which have not yet been read over the remote
interface.
Reply format: {CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-body{CR}Sub-
body, where Sub-body= ABCddmmyyhhmmss,
A being the fault/clear indicator, where:
F = Fault
C = Clear
I = Info
B being the fault type, where:
1 = Unit
2 = Rx Traffic
3 = Tx Traffic
4 = ODU
5 = Power on/off, or log cleared
C is Fault Code numbers, as in FLT? or Info Code, where:
0 = Power Off
Description of Arguments
8–26
MN-CDM570A
Revision 3
Query
Response to
(Instruction Code
Command
and Qualifier)
MSK= MSK? MSK=abcdefghijkl
MSK? (see Description of
MSK* Arguments)
MSK#
N/A RNE? RNE={CR}ABCddm
myyhhmmss{CR}A
BCddmmyyhhmms
s{CR}ABCddmmyy
hhmmss{CR}ABCd
dmmyyhhmmss
{CR}ABCddmmyyh
hmmss (see
Description of
Arguments)
Response to
Query
