3.1 Overview – Cabling Connection Types
The CDM-570A/570AL and CDMR-570AL Satellite Modems, with or without the optional High-
Performance Packet Processor, use a number of different cables. Each cable type is typically
dedicated to a specific mode of operation.
1) Not all of these operational interface types may be available.
2) The European EMC Directive (EN55022, EN50082-1) requires using properly
shielded cables for DATA I/O. These cables must be double-shielded from end-to-
end, ensuring a continuous ground shield.
