CDM-570A/570AL Satellite Modem with Optional Packet Processor
Installation and Startup
2.5
Connect the External Cables
Once the desired configuration settings have been made, and proper operation has been
verified using the IF Loopback test mode, proceed to connect all external cables to the
connectors outlined in the next chapter (Chapter 3. REAR PANEL CONNECTORS
Should difficulties occur, call Comtech EF Data Product Support for assistance.
2–6
MN-CDM570A
Revision 3
PINOUTS).
