CDM-570A/570AL Satellite Modem with Optional Packet Processor
Serial-based Remote Product Management
Command
Parameter (Instruction
Type Code and
Qualifier)
Equipment ID in
CDM-570A
Compatible Mode
(CMO=1)
(continued)
Equipment ID N/A 11 bytes
in CDM-570
Compatible Mode
(CMO=0)
Arguments for
Command or
Response to
Query
r = IP QoS option:
0 = None
1 = Installed
s = Vipersat option:
0 = None
1 = Installed
t = VFS data rate option:
0 = None
1 = full 512 kbps
2= full 1100 kbps
3 = full 2500 kbps
Installed Hardware:
A = TPC 0.95 card
0 = None
1 = Installed
B = CnC card
0 = None
1 = Installed
C = Expansion card
0 = None
1 = Installed
D = Packet Processor card
0 = None
1 = Installed
uuuuuuuuuu = spares (0)
Query only.
Returns information concerning the equipment identification and the option field, in
CDM-570 Compatible Mode (CMO=0), in the form abbbcdefghi; where:
a = Turbo option:
0 = None,
1 = Turbo
bbb defines the modem model number:
570 = CDM-570A, 571 = CDM/R-570AL
c = Expansion slot:
0 = None
1 = Reed-Solomon codec installed
d = Data Rate Option:
0 = Base (512 kbps)
1 = up to 2048 kbps
2 = up to 5000 kbps
Description of Arguments
8–41
MN-CDM570A
Revision 3
Query
Response to
(Instruction Code
Command
and Qualifier)
N/A EID? EID= abbbcdefghi
(see Description of
Arguments)
570 is the CDM-
570A
571 is the CDM-
570A L-Band
Response to
Query
