G.5.2.1 Estimate PSD Ratio from LST
G.5.2.2 Estimate PSD Ratio from Satmaster
Carrier A to B
Carrier B to A
PSD (Carrier A->B)
= 24.34 – 10 * log(2.3441 x 10
= – 39.36 dBW/Hz
PSD (Carrier B->A)
= 21.88 – 10 * log(2.3441 x 10
= – 41.82 dBW/Hz
PSD Ratio
± 2.46 dB
CnC Ratio
± 2.46 dB
