CDM-570A/570AL Satellite Modem with Optional Packet Processor
CDM-570A/570AL ODU (Transceiver, BUC, LNB) Operation
This screen summarizes the CSAT's current operational status. If any item displays "FT"
instead of "OK" then that feature is faulted. View the Stored Events Log for further details.
(ODU SELECT ► ALARMS:) Stored
Stored Events:
Clear All
Use the ◄ ► arrow keys to select View or Clear All, and then press ENTER.
(ODU SELECT ► ALARMS:) Stored ► View
LOG 02:11/13/99 10:42:47
OK- REF
Per the example shown, use the ▲▼arrow keys to sequentially view the individual
entries in the Stored Events Log. Otherwise, press CLEAR to return to the previous
menu.
(ODU SELECT ► ALARMS:) Stored ► Clear All
PRESS ENT TO
CLEAR THE EVENTS LOG
Press ENTER to clear the Stored Events Log. Otherwise, press CLEAR to return to the
previous menu.
View
(◄ ►,ENT)
LOCK (▲ ▼)
10–17
MN-CDM570A
Revision 3
