Comtech EF Data CDM-570A Installation And Operation Manual page 389

CDM-570A/570AL Satellite Modem with Optional Packet Processor
CDM-570A/570AL ODU (Transceiver, BUC, LNB) Operation
(ODU CONFIG ► ODU TX:) Mute
ODU Tx Mute State:
Muted
Use the ◄ ► arrow keys to select Muted or Unmuted, and then press ENTER.
(ODU CONFIG ► ODU TX:) Slope
ODU Tx Slope Mode:
Manual
Use the
(ODU CONFIG ► ODU TX:) Slope ► Manual
ODU Tx Slope:
0.0
Use the ▲▼arrow keys to edit the transmit slope setting, and then press ENTER.
(ODU CONFIG ► ODU TX:) Slope ► Calibrated
Calibrate TX Slope?
Cal
Use the ◄ ► arrow keys to select Cal or Exit, and then press ENTER.
(ODU CONFIG:) Receiver
ODU RX: Frequency Atten
Mute Slope
◄ ►
Use the
ENTER.
(ODU CONFIG ► ODU RX:) Frequency
ODU Rx Frequency:
5912.5 MHz (
To edit the receiver frequency: First, use the ◄ ► arrow keys to select a digit, and then
use the ▲▼arrow keys to change the value of that digit. Press ENTER when done.
(ODU CONFIG ► ODU RX:) Atten (Attenuation)
ODU Rx Attenuation:
15.00 dB
To edit the receiver attenuation: First, use the ◄ ► arrow keys to select a digit, and
then use the ▲▼arrow keys to change the value of that digit. Press ENTER when done.
Unmuted (◄ ►,ENT)
Calibrated
◄ ►
the arrow keys to select Manual or Calibrated, and then press ENTER.
(
▲ ▼,
Exit (◄ ►,ENT)
( ,ENT)
◄ ►
the arrow keys to select Frequency, Atten, Mute, or Slope, and then press
◄ ►,▲ ▼,
(◄ ►,▲ ▼,ENT)
(◄ ►)
ENT)
ENT)
10–11
MN-CDM570A
Revision 3
