CDM-570A/570AL Satellite Modem with Optional Packet Processor
Front Panel Operation
Demod: Not Locked
Press ENTER or CLEAR to return to the previous menu.
6.3.3.3

Monitor: ACM

This screen is viewable only when the optional Packet Processor is installed.
TxModCod=11 16QAM .853
RemoteSNR=99.9dB
Use the ▲▼arrow keys to toggle between the Tx and Rx ACM screens:
RxModCod=00 BPSK .488
LocalSNR=99.9dB
6.3.3.4

MONITOR: Event (Stored Events)

Stored Events:
Clear-All
◄ ►
arrow keys to select View or Clear-All. Press ENTER.
Use the
6.3.3.4.1

(MONITOR: Stored Events) View

Log23: 30/11/02 10:37:32
Fault - Demod Lock (▲ ▼)
When a fault condition occurs, the modem date- and time-stamps the fault, and enters it into
the Stored Events Log. The modem also records when the fault condition clears, as this example
shows:
Log240:30/11/97 10:37:35
Clear – Demod Lock(▲ ▼)
The Stored Events Log stores up to 255 events. Use the ▲▼arrow keys to browse through the
available entries. Press ENTER or CLEAR to return to the previous menu.
6.3.3.4.2

(MONITOR: Stored Events) Clear-All

Clear all Stored Events?
No Yes
Use the ▲▼arrow keys to select No or Yes. Press ENTER.
RSL=-64
(▲▼)
(▲▼)
View
(◄ ►,ENTER)
(▲ ▼, ENTER)
6–43
MN-CDM570A
Revision 3
