CDM-570A/570AL Satellite Modem with Optional Packet Processor
CDM-570A/570AL ODU (Transceiver, BUC, LNB) Operation
10.2.3 Transceiver M&C via CDM-570A Serial Remote Control
Chapter 8. SERIAL-BASED REMOTE PRODUCT MANAGEMENT

10.2.3.1 CDM-570A Transceiver Remote Control Address Setup

Appendix J. EDMAC CHANNEL
The ODU, as connected to a CDM-570A through FSK (Frequency Shift Keying), can be remotely
monitored and controlled through the use of ODU commands and queries issued via serial
remote control. The address of the ODU is set up as follows:
•
For Local-End ODUs:
o Use the Modem's RC Address + 1 for the Standalone or Online Unit in a 1:1
Redundancy System;
o Use the Modem's RC Address + 2 for the Offline Unit in a 1:1 Redundancy System.
•
For Distant-End ODUs in an EDMAC setup:
o Use the EDMAC Slave Address (ESA) Range +4 for Standalone Unit or the Online Unit in
a 1:1 Redundancy System;
o Use the EDMAC Slave Address (ESA) Range +5 for the Offline Unit in a 1:1 Redundancy
System.
10–36
MN-CDM570A
Revision 3
