CDM-570A/570AL Satellite Modem with Optional Packet Processor
Serial-based Remote Product Management
Command
Parameter (Instruction
Type Code and
Qualifier)
Rx FEC Code RCR= 1 byte,
Rate value of 0 thru 7,
A to R
Rx Data Rate RDR= 9 bytes
Arguments for
Command or
Response to
Query
Command or Query.
Sets or returns Rx FEC Code Rate in the form x, where:
0 = Rate 5/16 (Turbo Only)
1 = Rate 21/44 (Turbo Only)
2 = Rate 1/2
3 = Rate 2/3 (8-PSK TCM or 8-QAM only)
4 = Rate 3/4
5 = Rate 7/8
6 = Rate 0.95 (Turbo Only)
7 = Rate 1/1 (Uncoded or No FEC)
8 = Reserved
9 = Reserved
The remaining entries are valid only in CDM-570A Compatible Mode
(CMO=1):
A = VersaFEC CCM – BPSK Rate 0.488
B = VersaFEC CCM – QPSK Rate 0.533
C = VersaFEC CCM – QPSK Rate 0.631
D = VersaFEC CCM – QPSK Rate 0.706
E = VersaFEC CCM – QPSK Rate 0.0803
F = VersaFEC CCM – 8-QAM Rate 0.576
G = VersaFEC CCM – 8-QAM Rate 0.642
H = VersaFEC CCM – 8-QAM Rate 0.711
I = VersaFEC CCM – 8-QAM Rate 0.780
J = VersaFEC CCM – 16-QAM Rate 0.644
K = VersaFEC CCM – 16-QAM Rate 0.731
L = VersaFEC CCM – 16-QAM Rate 0.780
M = VersaFEC CCM – 16-QAM Rate 0.829
N = VersaFEC CCM – 16-QAM Rate 0.853
O = VersaFEC CCM ULL– BPSK Rate 0.493
P = VersaFEC CCM ULL– QPSK Rate 0.493
Q = VersaFEC CCM ULL– QPSK Rate 0.654
R = VersaFEC CCM ULL– QPSK Rate 0.734
Note: Selection availability depends on the active FEC and demodulation
type.
Example: <0/RCR=1 (Rate 3/4)
Command or Query.
Sets or returns Rx Data Rate in the form xxxxx.xx, where:
xxxxx.xx = value from 2.4 kbps to 10240 kbps
Resolution = 1 bps
Example: <0/RDR=2047.999
Description of Arguments
8–19
MN-CDM570A
Revision 3
Query
Response to
(Instruction Code
Command
and Qualifier)
RCR= RCR? RCR=x
RCR? (see Description
RCR* of Arguments)
RCR#
RCR+
RDR= RDR? RDR=xxxxx.xxx
RDR? (see Description
RDR* of Arguments)
RDR#
Response to
Query
