CDM-570A/570AL Satellite Modem with Optional Packet Processor
Updating Firmware
•
•
Using the CDM-570A/570AL Serial Remote Interface (via the User PC / terminal
emulator program):
•
•
2. Next, create a temporary folder (subdirectory) on the User PC for the firmware archive
download.
•
•
There are several ways to create a temporary folder on a Windows-based PC:
a) Use the Windows Desktop to create and rename the temporary folder.
•
Right-click anywhere on the desktop to open the popup submenu, and then select
New > Folder to create a temporary folder on the desktop.
Packet Processor Firmware Info – Use the 'Admin | Firmware | Packet
Processor' page, as shown in this example:
Ethernet IP Address – Use the 'Configuration | LAN' page to view the IP
Address/Mask, as shown in this example:
Firmware Info – Use the <0/SWR? (condensed) or <0/FRW? (detailed) remote
query.
Ethernet Traffic IP Address – Use the <0/IPA? remote query.
Drive letter "c:" is used in these examples. Any valid, writable drive letter can
be used.
Typical for all tasks: Type the command without quotes , and then press Enter
to execute.
