Polycom RMX 1500 Administrator's Manual page 606

Chapter 17-Gateway Calls
17-16
The New Conference IVR Service - Video Services dialog box opens.
13 Define the following parameters:
Table 17-2 New Conference IVR Service Properties - Video Services
Parameters
Video
Services
Click&View
Video
Welcome Slide
14 Click the DTMF Codes tab.
The New Conference IVR Service - DTMF Codes dialog box opens.
15 If required, modify the DTMF codes or permissions. For more details,
see RMX 1500/2000/4000 Administrator's Guide, "New Conference IVR
Service Properties - DTMF Codes" on page 15-25.
16 Click the Operator Assistance tab.
17 If Operator Assistance will not be available to participants, clear the
Enable Operator Assistance option, which is automatically selected
to disable it.
18 Click OK to complete the IVR Service definition.
The new Conference IVR Service is added to the IVR Services list.
Description
Select this option to enable endpoints to run the
Click&View application that enables participants to
select a video layout from their endpoint.
Select the video slide file to be displayed when
participants connect to the conference. To view any
slide, click the Preview Slide
If the video slide file was not uploaded to the MCU prior
to the IVR Service definition, click the Add Slide button.
The Install File dialog box opens. The uploading
process is similar to the uploading of audio files. For
more information, see step 7 on page
1500/2000/4000 Administrator's Guide.
Notes:
• When using one of the default Polycom slides, the
slide will be displayed in the resolution defined in the
profile, i.e. CIF, SD, HD 720p or HD 1080p.
• When defining a gateway IVR Service, the
recommended default slide is:
Default_GW_Welcome_Slide.
(
) button.
17-14 in the RMX
