The Insert Accept Packet IP Address dialog box opens.
19. Enter the IP Address of the Manager terminal from which valid queries
may be sent to the MCU, and then click OK.
The IP Address is displayed in the Accept SNMP Packets from These
Hosts box.
20. To edit the IP address of a specific Manager terminal:
— Select the relevant IP address, and then click the Edit button.
The Edit Trap Destination IP dialog box opens.
— Modify the IP address, and then click OK.
The modified IP address is displayed in the Accept SNMP Packets
from These Hosts box.
21. To delete a specific Manager terminal's IP address:
— Select the IP address, and then click the Remove button.
The IP address is removed from the Accept SNMP Packets from
These Hosts box.
Queries sent from terminals not listed in the Accept SNMP Packets from These
Hosts box are regarded as a violation of the MCU security, and if the Send
Authentication Trap check box is selected, an appropriate message will be sent
to all the terminals listed in the SNMP Properties – Traps dialog box.
22. In the MCU - SNMP properties dialog box, click OK.
MGC Administrator's Guide
5-53
