Chapter 4 - MCU Card Management
4-8
When double-clicking the Cards icon in the Browser pane, the Status
pane displays the status of each card.
Occupied slots appear in green while empty slots appear in white. The
slot number appears next to the slot icon. Table 4-2 describes the Status
pane columns.
Table 4-2: MCU's Cards Status Columns
Field
Slot
Description
Displays the slot icon and number; a white icon
indicates an empty slot and a green icon indicates an
occupied slot.
