Chapter 3 - Defining Network Services
3-62
Table 3-16: Add Router Dialog Box Options (Continued)
Field
Type
c. Click OK.
The system returns to the Settings dialog box, displaying the added
static route.
Defining Quality of Service
QoS can be measured and guaranteed in average delay between packets, the
variation in delay, and the transmission error rate. Currently, two QoS
methods are supported: DiffServ and Precedence. These methods differ in the
way the packet's priority is encoded in the packet header.
7. To define Quality of Service parameters:
a. Click the Quality of Service button.
The QoS of Ethernet Service dialog box opens.
Description
Select the type of router connection:
•
Network – defines a connection to a router
segment in another network.
•
Host – defines a direct connection to an endpoint
found on another network.
