Polycom MGC Administrator Administrator's Manual page 131

Table 3-24: SIP Settings Dialog Box Options (Continued)
Field
Outbound Proxy
Outbound Proxy is
different than SIP
Server
IP Address or
Name
Port
c. Click OK to apply the manual server settings and return to the SIP
dialog box.
15. Click Next.
Description
Select this check box if the outbound proxy is
installed on a different computer than the one the SIP
server is installed on.
Usually these two entities reside on the same
machine (both identification and forwarding the users
to their destination). But in the instance that they are
not and the entity that deals with identifying and
registering users is on a different machine, select this
check box.
If you have selected Outbound Proxy is different than
SIP Server, enter either the IP address of the
outbound proxy or its host name (if a DNS server is
used).
Enter the port number the outbound proxy is listening
to. The default port is 5060.
MGC Administrator's Guide
3-81
