ATM Setup Flow

Defining a New ATM Network Service

ATM setup and configuration consist of the following procedures:
Defining the ATM Network Service. For details, see "Defining a New
•
ATM Network Service" on page 3-114.
Configuring the ATM card. For details, "Assigning the ATM Network
•
Service to the ATM Network Interface Module" on page 3-121.
• Defining the UNI address of the MCU and the endpoints in the V-Gate.
To accomplish this task you will need to obtain the UNI number of the
ATM card installed in the MCU. For details on how to obtain the UNI
address and define these numbers in the V-Gate application refer to the
V-Gate's User's Guide.
These steps are identical for ATM-25 and ATM-155 Network Interface
Modules.
The ATM Network Service is used to define the UNI address of the V-Gate,
which allows communication between the MCU and the V-Gate. In addition,
you need to define the span and the dial-in phone numbers to be used by the
conference participants.
Before defining an ATM service, you should:
Make sure that the ATM Network Interface module is installed in the
•
MCU. If not, install it first.
Obtain the UNI address of the V-Gate.
•
Make sure that the MCU power is on.
•
To define a new ATM Network Service:
1. Connect the MGC Manager to the MCU. For more information, see the
MGC Manager User's Guide, Volume 1, Chapter 3, "Connecting to an
MCU".
2. In the Browser pane, double-click the MCU icon, or click the plus [+]
icon next to the MCU icon.
A list of options is displayed below the MCU icon.
3. In the MCU options list, double-click the MCU Configuration icon, or
click the plus [+] icon next to the MCU Configuration icon.
