Chapter 7 - Configuring the Gateway
7-72
Parameters on the left side define the activity of the local gateway. The
parameters on the right side define the activity of the remote gateway.
5. Define the following parameters:
Table 7-13: Gateway Link Options
Field
Link Name
Link ID
Link DID
Local GW Session
Profile Name
Connection Type to
Remote GW
Remote GW Name
Description
Enter the gateway link name; it is advised to
associate the name with the call type.
Enter the H.323 Link ID number. The endpoint will
call the link and connect to the Double/Multiple
gateway during call setup.
This field is disabled if no dial-in numbers were
defined in the H.320 Routing Services table.
Enter the H.320 Link DID number. The endpoint will
call the link in order to connect to the Double/Multiple
gateway (This number is retrieved from the H.320
Routing Services table where it is defined as the Dial-
in number).
Select from the drop-down list the Session Profile to
use. The available Session Profiles depend on the
Connection Type to Remote GW selection.
Define the connection type (backbone) of the remote
gateway, either H.320 or H.323.
H.320 - Selects H.320 as the network connection
protocol for linking to the remote gateway. Possible
connection methods include:
•
H.323 Destinations
•
Address Book
•
Forwarding Service
H.323 - Selects H.323 as the network connection
protocol for linking to the remote gateway. Possible
connection methods include:
• Address Book
•
Profile
Select from the Remote GW Name list the name of
the Remote Gateway.
