Polycom MGC Administrator Administrator's Manual page 459

Table 7-7: Address Book - Endpoint Definition Options (Continued)
Field
H.323 Endpoint ID
(E164)
Session Profile/
Network Service
H.320 Network Sub
Service
Description
A number in E.164 format that identifies this
endpoint. When dialing from an H.323 endpoint this
number is used for speed dialing, and indicates an
entry in the Address Book. When this number is
dialed by the H.323 endpoint, the gateway looks for
the destination endpoint parameters in the Address
Book table, and routes the call to the destination
endpoint according to the properties defined there.
For example if you enter 88 as the H.323 Endpoint
ID, when entering the string # 88, the gateway will
take the endpoint parameters from the Address Book
entry identified by the digits 88.
Select (from the two option buttons) whether the
session parameters are taken from the Session
Profile, or are defined in this dialog box.
•
Select the Session Profile option to take the
Network Service definition and the session
parameters from the Session Profile. Then select
the session profile to be used for handling the call
to this endpoint.
Note: The Session Profile list displays the default
Session Profile according to the destination
endpoint type.
•
Select the Network Service option to define the
session parameters and select the Network
Service to handle the call in this dialog box. Then
select from the dropdown list the Network
Service.
Note: The Network Service list displays the
default Network Service, according to the
selected endpoint type (H.320 or H.323).
Select the H.320 Sub Network Service. This field
displays the default Sub Network Service.
Note: This field is optional.
MGC Administrator's Guide
7-51
