Chapter 4 - MCU Card Management
Viewing the Net-2/Net-4/Net-8 Card Properties
4-14
To connect the MCU to the ISDN network switch, you need to assign the
ISDN Network Service to the appropriate span of the Net-2/Net-4/Net-8
Network Interface module. For details, see Chapter 3, "Assigning the ISDN
Network Service to the Net-2/Net-4/Net-8 Card" on page 3-34.
In the same way, to connect the MCU to T1-CAS lines, you need to assign the
T1-CAS Network Service to the appropriate span of the Net-2/Net-4/Net-8
Network Interface module. For details, see Chapter 3, "Assigning the T1-
CAS Network Service to the Net-2/Net-4/Net-8 Card" on page 3-46.
It is not possible to mix an ISDN Network Service and a T1-CAS Network Service
on the same Net-2/Net-4/Net-8 Network Interface module. Therefore, the Net-2/
Net-4/Net-8 card can only be used with either ISDN or T1-CAS Network Service.
Before you assign the T1-CAS Network Service to the card, you must set the
following 'system.cfg' flag: in the NET8_PARAMETERS section, set
NET8_DEFAULT_TYPE = to T1-CAS.
In addition, you may define which span in the network interface card will be
used as the primary clock and which one as the backup clock to synchronize
with the network clock. For details, see Chapter 5, "Clocking" on page 5-132.
To view the Net-2/Net-4/Net-8 ISDN card properties:
1.
In the Browser pane, right-click the slot containing the
Net-2/4/8 card, and then click Properties.
Alternatively, double-click the slot containing the card.
The Card Settings – Common Parameters dialog box opens. For details,
see "Viewing the Common Card Parameters" on page 4-10.
2.
To view the status of the connection to Net-2/Net-4/Net-8 card, click the
NET–8 Network Parameters tab.
