Appendix D: The Falcon Diagnostic Tool

Using the Falcon Diagnostic Tool

D-8
The Falcon tool is part of the MGC Manager Options menu.
To Start the Falcon Diagnostics Tool:
1. Terminate all On Going Conferences and cancel any soon to open
Reservations on the MCUs to be tested.
2. In the Options menu, select Open Diagnostics tool.
The Falcon diagnostics tool opens.
The Falcon diagnostics tool displays all the MCUs currently defined in
the MGC Manager, see "Falcon Main Window" on page D-9. You can
define other MCUs so they can be displayed in the MGC Manager and in
the Falcon tool.
The MCU network is displayed in a Browser pane on the left side of the
Falcon screen.
