Polycom MGC Administrator Administrator's Manual page 468

Chapter 7 - Configuring the Gateway
7-60
Table 7-8: Routing Services Options (Continued)
Field
Network Service
Name
First Dial-in Number
Last Dial-in Number
DID/Alias
Conversion/Address
Book/Forwarding
Services List
To define the DID to H.323 Conversion table:
3. Click the plus [+] icon to add a new entry to the conversion table.
The DID to H.323 ID Conversion dialog box opens.
4. Define the following parameters:
Table 7-9: DID to H.323 ID Conversion Options
Field
DID Number
Description
Displays the name of the Network Service for
reference, but the field cannot be modified.
Displays the first number of a selected dial-in range.
Displays the last number of a selected dial-in range.
Displays different parameters depending on the
Routing Method.
Description
Select the DID numbers to which to assign the H.323
endpoint IP address or Alias.
The DID number may be selected from the DID
number range allocated to this Routing Service.
