Chapter 4 - MCU Card Management
4-26
LAN
The Card Settings-LAN tab displays information derived from the network.
Table 4-10: Card Settings–LAN
Field
Status
Link Status
Speed(Mbps)
Duplex
Description
The status of the link from card to the hub/switch. Options
are OK or Fail.
Indicates the transfer rate between the card and the hub/
switch. It can be 10 Mbits/Sec or 100 Mbits/Sec.
Full duplex means that transmit and receive operations
can proceed simultaneously between the card and the
hub. If the service is set to Video Bit Rate of 10 bits/sec,
the system will always work in half duplex.
