Common Parameters; Ip-Network Parameters - Polycom MGC Administrator Administrator's Manual

Table 4-5: IP Card Types (Continued)
IP Card Name
IP+12
IP+24
IP+48
HW Version SIP Support
> 4.41
> 4.41
> 4.41
To view the IP card properties:
1. Expand the MCU tree.
2. Expand the MCU Configuration tree
3. Expand the Cards tree.
4. Right-click the IP card icon and click Properties, or double-click the
card.
The IP card properties are described in six tabs:

— Common Parameters

— IP-Network Parameters

— DNS
— H.323
— SIP
— LAN
Common Parameters
The Common Parameters tab is for viewing purposes only and displays the
following information: slot number, card type, hardware version number,
software version number, serial number, card status, and conferences that are
currently running on this card. The card's common parameters are detailed in
the MGC Administrator's Guide, Chapter 4, "Viewing the Common Card
Parameters".
Number of
Units
+ 1
+ 2
+ 3
MGC Administrator's Guide
VOIP Call Encryption
Capacity
32
64
96
4-17
