Test Options Box
The Test Options box displays the modes for running tests.
Table D-3: Test Options Description
Field
Loop Test
Stop on Failure
Quick Test
If no selection is made in the Test Options box, the tests will run one time.
Test Selection
The Test Selection box displays the tests that are available for the selected
element.
All - Selects all the diagnostic tests to run. Tests vary depending on the
selected MCU component, for details, see Table D-1 on page D-3. When the
MCU icon or card icon is selected, all tests are run by default. When a card
unit is selected, tests can be selected individually.
Run button - Initiates the diagnostic tests that are selected.
Stop button - Terminates on going diagnostic tests.
IP Test Box
The IP Test box is active during the LAN test. The IP Address, Subnet Mask
and Default Gateway information must be entered. If these parameters are not
entered, a pop-up box appears when the diagnostics run the LAN test, and
these fields must be entered at that time. You can cancel the LAN test instead
of entering the IP Test values.
IP Address - This is the address of the card and should be provided by the
System Administrator.
Subnet Mask - This is provided by the System Administrator.
Default Gateway - This is necessary to test the LAN Controller.
Description
Sets tests to repeat continuously in a loop mode.
This provides continuous testing for these
diagnostics.
In this mode tests are run continuously until a failure
is detected. The diagnostic testing then stops.
Enables running tests that do not run longer than 5
minutes. On the MGC-25, all tests run as they all
take less than 5 minutes to run.
