Polycom MGC Administrator Administrator's Manual page 285

Table 5-12: SNMP Properties – Traps Options (Continued)
Field
Trap Destination
6. Click the Add button to add a new Manager terminal.
The Insert Trap Destination IP dialog box opens.
7. Type the IP address of the Manager terminal used to monitor the MCU
activity, and then click OK.
The new IP address is added to the Trap Destinations box.
8. To edit the IP Address of a Manager terminal:
— Select the address that you wish to modify, and then click the Edit
button.
The Edit Trap Destination IP dialog box opens.
— Edit the IP address, and then click OK.
The IP address in the Trap Destinations box is modified.
9. To delete the IP Address of a Manager terminal:
— Select the address that you wish to delete, and then click the
Remove button.
The IP address in the Trap Destinations box is removed.
Description
This box lists the currently defined IP addresses of
the Manager terminals to which the message (trap) is
sent.
MGC Administrator's Guide
5-49
