Polycom MGC Administrator Administrator's Manual page 469

Table 7-9: DID to H.323 ID Conversion Options (Continued)
Field
Endpoint
Description
IP Address
Alias Type
Alias Name
5. Click the Apply button to add the new entry to the conversion table and
define an additional entry, repeating steps 3 to 4.
Alternatively,
click OK to add the new entry to the conversion table and return to the
H.320 Routing Services Definition dialog box.
6. In the H.320 Routing Services Definition dialog box, click Close to
return to the From H.320 Routing Services Definition dialog box.
7. Define the properties of additional Routing Services by double-clicking
the appropriate Routing Service.
8. Complete the definition and exit this dialog box by clicking the Close
button.
For additional explanations on the Address Book Properties definition,
see page 7-62.
Description
Enter a description of the endpoint to identify it. For
example, enter the name of the user to whom the
endpoint is assigned.
Enter the destination endpoint IP address.
Note: Usually you will enter either the IP Address or
an Alias Name of the endpoint. When an
incoming call arrives at the Gateway with a DID
number, the system will route the call to the
endpoint according to the IP Address or Alias
defined in the conversion table for that DID. If
no entry is defined in the conversion table the
DID number will be considered as the Alias in
E.164 format.
Select the format of the alias name from the drop
down list. Select either E164 or H323ID (the other
formats are not supported by the gateway).
Any given name that is assigned to the H.323
Endpoint. Enter the Alias name using the naming
conventions appropriate to the Alias Type.
MGC Administrator's Guide
7-61
