Polycom MGC Administrator Administrator's Manual page 304

Chapter 5 - MCU System Management
5-68
CONFERENCE_ID_USER_LENGTH = 4
•
Defines the number of digits that the Operator must enter when manually
assigning the Numeric ID to the conference. Possible values are 1 to16
digits. Enter 0 to disable checking of the Numeric ID length.
RESERVATION_CONFERENCE_ID_UNIQUE = YES
•
If set to NO - duplicate NIDs are allowed in reservations. In this case, it's
the administrator's responsibility to make sure there is no overlapping
reservations with same NID planned for the same time.
• PREFERRED_PORT = 80
80 - Any port can be used and is the preferred port with XML
5001 or 1205 - the http port not activated and uses the proprietary API.
ENABLE_DTMF_VIA_GW = YES
•
Enables/disables DTMF Forwarding (user to user) in a gateway
conference.
ENABLE_LECTURE_SHOW = YES
•
Enables/disables the Lecture Show feature.
Section QOS PARAMS
• DIFF_SERV_AUDIO = 0X88
The diffserv value for audio packets.
DIFF_SERV_VIDEO = 0X88
•
The diffserv value for video packets.
Section IP MISC FLAGS
PARTY_MONITORING_REFRESH_PERIOD= 2
•
The party monitoring is a request that the MCMS sends to the IP card.
This flag helps to determine the load of those request by identifying the
number of seconds between each party monitoring request.
IP_ENABLE_ROUNDTRIPDELAY = YES
•
When an endpoint disconnects from the conference, the MCU perceives
the endpoint to be connected but not responding. To disconnect the
endpoint the MCU sends a Round Trip Delay request to the endpoint. If
the endpoint fails to respond, it is disconnected from the MCU.
