Chapter 4 - MCU Card Management
Viewing the NET-T1/NET-E1 Card Properties
4-12
To connect the MCU to the ISDN network switch, you need to assign the
ISDN Network Service to the appropriate span of the Net-T1/Net-E1Network
Interface module. For details, see Chapter 3, "Assigning the ISDN Network
Service to the NET-T1/NET-E1 Card" on page 3-29.
To view the Net-T1/Net-E1 ISDN card properties:
1.
In the Browser pane, right-click the slot containing the Net-E1/T1 card,
indicated by PRI48 and PRI64, and then click Properties.
Alternatively, double-click the slot containing the card.
The Card Settings–Common Parameters dialog box opens. For details,
see "Viewing the Common Card Parameters" on page 4-10.
2.
To view the status of the connection to Net-E1/T1 card, click the
Network Parameters tab.
